Maintenance
Inspection guide
The purpose of this inspection guide is to aid you in identifying the intervals, based on page count, at which
parts must be inspected (for visible physical damage), cleaned, or replaced.
If any unsafe conditions exist, find out how serious the hazard could be and if you can continue before you
correct the hazard.
As you service the machine, check for the following:
• Damaged, missing, or altered parts, especially in the area of the On/O switch and the power supply
• Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover
• Possible safety exposure from any non-Lexmark attachments
Use the following table to determine when specified parts should be inspected:
PART EVERY SERVICE CALL EVERY 200K
Fuser Inspect Replace
MPF pick roller and separator pad Inspect Replace
Pick tires Inspect Replace
Separator roller assembly Inspect Replace
Transfer roller Inspect Replace
Scheduled maintenance
The control panel displays an 80.xx error when it reaches a preset number of page counts. It is necessary to
install the appropriate maintenance kit to maintain the print quality and reliability of the printer. Reset the
maintenance counter after replacing the maintenance kit.
Maintenance kits
Part number and kit Contents
41X1227—Maintenance Kit (100 V)
• 41X1180—Fuser (100 V)
• 41X1197—MPF pick roller and separator pad
• 41X1198—Pick tires
• 41X1212—Separator roller assembly
• 40X8393—Transfer roller
41X1225—Maintenance Kit (110 V)
• 41X1178—Fuser (110 V)
• 41X1197—MPF pick roller and separator pad
• 41X1198—Pick tires
• 41X1212—Separator roller assembly
• 40X8393—Transfer roller
4600-830, -835, -895
Maintenance
255

Lexmark MS621dn Specifications

General

Display	LCD
Certification	ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN / CSA-C22.2 60950-1, NOM, CB EN / IEC 60950-1 , CB EN / IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN / IEC 60950-1, CE EN / IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024 , UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC1275, MET-I, ISO 532B, ECMA-370, TED, GOST -R, SII, TER
Product color	Anthracite, White
Built-in display	Yes
Display diagonal	2.4 \
Market positioning	Enterprise
Power consumption (off)	0.1 W
Power consumption (ready)	9.5 W
Power consumption (standby)	2.2 W
Power consumption (printing)	670 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Print technology	Laser
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	24 ppm
Printing colors	Black
Country of origin	China
Maximum duty cycle	175000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PDF 1.7, PPDS, PostScript 3
Processor cores	2
Processor frequency	1000 MHz
Sound power level (standby)	14 dB
Sound pressure level (printing)	56 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Fedora 23, Fedora 24, Fedora 25, Fedora 26, Fedora 27, Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, openSUSE 13.2, openSUSE 42.3
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Novell Open Enterprise Server 11, Novell Open Enterprise Server 2
Server operating systems supported	SUSE Linux Enterprise Server 10, SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Maximum number of input trays	5
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Envelopes, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 5000 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	470 mm
Package width	430 mm
Package height	422 mm
Package weight	17760 g
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, LEAP, MD5, MSCHAPv2, PEAP, SSH, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Supported network protocols (IPv4)	TCP/IP IPv6, TCP/IP IPv4, AppleTalk, TCP, UDP
Cables included	AC
USB connector	USB Type-A / USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	374 mm
Width	399 mm
Height	303 mm
