Lexmark MS621dn

6 Remove the clip (D).
D
B
C
A
C
7 Remove the cover.
Sensor (front door) removal
1 Remove the nameplate. See “Nameplate removal” on page 201.
2 Remove the right cover. See “Right cover removal” on page 186.
3 Disconnect the JCVR1 and control panel cables from the controller board.
4600-830, -835, -895
Parts removal
207
