Assembly 29: Staple finisher 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8222 1 1 Staple finisher top
cover
“Staple finisher top cover removal” on
page 588
2 41X2169 1 1 Staple finisher rear
door
“Staple finisher rear door removal” on
page 582
3 41X1698 1 1 Staple finisher right
cover
“Staple finisher right cover removal” on
page 586
4 41X1701 1 1 Staple cartridge access
door
“Staple cartridge access door removal”
on page 644
5 40X7466 1 1 Staple cartridge holder
“Staple cartridge holder removal” on
page 704
641X1704 1 1Standard bin LED
“Standard bin LED removal” on
page 602
7 41X1238 1 1 Sensor (finisher bin
paper present)
“Sensor (staple finisher bin paper
present) removal” on page 603
8 41X1715 1 1 Staple finisher left
cover
“Staple finisher left cover removal” on
page 584
4064
Parts catalog
830
To Next Page
