Lexmark MX910de Service Manual

• Hard disk memory—The printer hard disk is designed for printer-specific functionality and cannot be used for
the long‑term storage of data that is not print-related. The hard disk can retain buffered user data from complex
print jobs, form data, and font data.
To erase volatile memory, turn off the printer.
To erase the non-volatile and printer hard disk memory, see
“Configuration Menu” on page 229.
The following parts are capable of storing memory:
• Printer control panel
• User interface controller card (UICC)
• Controller board
• Optional hard disk
Note: The control panel and controller board contain NVRAM.
2 After removing the old part, return it to your next level of support.
Tools required for service
• Flat-blade screwdrivers, various sizes
• #1 Phillips screwdriver, magnetic
• #2 Phillips screwdriver, magnetic
• #2 Phillips screwdriver, magnetic short-blade
• Needle‑nose pliers
• Diagonal side cutters
• Spring hook
• Feeler gauges
• Analog or digital multimeter
• Flashlight (optional)
7421
General information
43

Lexmark MX910de Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.6 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Time to first copy (black, normal)	5.8 s
Copy speed (black, normal, US Letter)	45 cpm
Scan to	Image
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 432 mm
Scan speed (color)	80 ppm
Duplex scan speed (color)	140 ppm
Optical scanning resolution	600 x 600 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	-
Maximum duty cycle	200000 pages per month
Recommended duty cycle	15000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XHTML
Wi-Fi	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security features	HTTP HTTPs (SSL/TLS) SNMPv1, SNMPv2c SNMPv3 WINS IGMP BOOTP, RARP APIPA (AutoIP) DHCP ICMP DNS DDNS mDNS ARP NTP Telnet Finger
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Authentication method	802.1x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4 AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6 TCP UDP
Internal memory	1024 MB
Processor frequency	800 MHz
Maximum internal memory	3072 MB
Sound power level (standby)	29 dB
Sound pressure level (copying)	53 dB
Sound pressure level (printing)	52 dB
Sound pressure level (scanning)	57 dB
Sound pressure level (duplex printing)	55 dB
Paper input type	Paper tray
Total input capacity	1150 sheets
Total output capacity	250 sheets
Maximum input capacity	6650 sheets
Total number of input trays	3
Maximum number of input trays	6
Multi-Purpose tray input capacity	150 sheets
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Ledger (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Paper tray media weight (imperial)	16 - 68 lbs
Control type	Touch
Product color	White
Display diagonal	10 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	- W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	ENERGY STAR
Certification	ICES-003 Class A, BSMI Class A, VCCI Class A, FCC Class A, NOM-032, cTUV, US FDA/CDRH, cTUVus, IEC 60825-1, CB Report, NCC Mark, FCC, CE (EU) DoC, EFTA (CE), KCC, RCM, CCC, C-tick DoC, EuP, CECP, CEL, ECMA-370, TED, GOST-R, SII, TER, Bel GISS, SABS, TUV-AR, KC mark, BIS, TUV-GS Mark
Package depth	838 mm
Package width	762 mm
Package height	1194 mm
Package weight	111583 g
Operating altitude	0 - 2500 m
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	696 mm
Width	614.6 mm
Height	909 mm
Weight	94982 g
