Assembly 1: Covers 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X9924 1 1 Standard bin ‑‑
2 40X8901 1 1 Tray empty board cable ‑‑
3 40X9758 1 1 Tray empty board mount ‑‑
4 40X8903 2 1 Tray 1 empty indicator ‑‑
5 40X8902 1 1 Tray empty board cover ‑‑
6 40X8903 2 1 Tray 2 empty indicator ‑‑
7 40X8904 1 1 Front lower cover ‑‑
8 40X9962 1 1 Screwdriver ‑‑
9 40X9760 1 1 Bottom front door
“Bottom front door removal” on page 327
10 40X8905 1 1 Printhead cleaner ‑‑
11 40X9761 1 1 Bottom front door hinge ‑‑
12 40X8900 1 1 Top front door
“Top front door removal” on page 327
13 40X8906 2 1 Top front door outer hinge ‑‑
14 40X9917 2 1 Top front door inner hinge ‑‑
15 40X8898 1 1 Left cover
“Left cover removal” on page 272
16 40X8899 1 1 Rear left cover
“Rear left cover removal” on page 273
17 40X8897 1 1 Standard bin base
“Standard bin base removal” on page 389
7421
Parts catalog
544
