Lexmark MX910de - Page 726

Assembly 92: 2500-sheet tray insert 3
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X9796 1 1 Transfer guide primary gear --
2 40X9798 1 1 Main tray elevator coupling --
3 40X9901 2 1 Main tray elevator gear spring --
4 40X9902 1 1 Main tray elevator gear --
5 40X9797 1 1 Transfer guide primary gear spring --
6 40X9795 1 1 Transfer guide secondary gear --
7421
Parts catalog
726
