Loading the 2,000-sheet dual input trays
The 2,000-sheet dual input drawer includes two trays: an 850-sheet tray and a 1,150-sheet tray. Although the trays are
different in appearance, they require the same process for loading paper.
1 Pull the tray out.
2 Squeeze the length guide tab inward as shown, and slide the guide to the correct position for the paper size being
loaded.
3 Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the
edges on a level surface.
Loading paper and specialty media 49
