Understanding the parts of the printer
Understanding the parts of the printer
1
11
12
2
3
4
5
6
7
8
9
10
Use the To
1
PictBridge port Connect a PictBridge-enabled digital camera or a flash
drive to the printer.
2
Memory card slots Insert a memory card.
3
Control panel Operate the printer.
4
Paper exit tray Hold paper as it exits.
5
Automatic Document Feeder (ADF) paper guide Keep paper straight when feeding into the ADF.
6
Automatic Document Feeder (ADF) Scan, copy, or fax multiple-page letter-, legal-, and A4-size
documents.
7
Automatic Document Feeder (ADF) exit tray Hold paper as it exits the ADF.
8
Paper guide Keep paper straight when feeding.
9
Paper support Load paper.
10
Automatic Document Feeder (ADF) paper stop
• Stop paper as it exits the ADF.
• Support A4- and legal-size paper as it exits the ADF.
11
Scanner glass Copy, scan, fax, or remove an item.
12
Top cover Access the scanner glass.
