Repair information 4-249

7462

Go Back

Offset stacker sensor (media stack) removal

1. Remove the offset stacker top cover. See “Offset stacker top cover removal” on page 4-239.

2. Disconnect the harness to the sensor (media stack).

3. Using your fingers, pinch tab (A) securing the offset stacker sensor (media stack) and remove.
