Lexmark X850E - Replacing the Access Panel

Replacing the access panel
95
Installing options
Replacing the access panel
After you have installed options on the MFP system board, follow these steps to reattach the access panel.
1 Align the tabs on the right side of the access panel with the slots on the MFP.
2 Slide the panel to the right and towards the MFP.
3 Tighten the screws.
4 Plug the MFP power cord back into a properly grounded electrical outlet, and turn on the MFP.
