726
ES350_300h_OM_OM33A60U_(U)
6-3. Do-it-yourself maintenance
22 EFI NO.3
10*
2
Multiport fuel injection system, sequential
multiport fuel system, air intake system,
exhaust system
7. 5*
1
Multiport fuel injection system, sequential
multiport fuel system, air intake system
23 INJ 7. 5
Multiport fuel injection system, sequential
multiport fuel system
24 ECU-IG2 NO.3 7.5
Multiport fuel injection system, sequential
multiport fuel system, electronic controlled
transmission, power management system,
steering lock system, cruise control system
25 IGN 15 Starting system
26 D/L-AM2 25 Power door lock system
27 IG2-MAIN 25 INJ, IGN
28
ALT-S*
2
7. 5 Charging system
DC/DC-S*
1
7. 5 Hybrid system
29 MAYDAY 5 MAYDAY
30 TURN&HAZ 15 Turn signal lights, emergency flashers
31 STRG LOCK 10 Steering lock system
32 AMP 30 Audio system
33 H-LP LH-LO 15 Left-hand headlight
34 H-LP RH-LO 15 Right-hand headlight
35 EFI-MAIN NO.1 30 EFI NO.2, EFI NO.3, fuel system
36 SMART 5
Smart access system with push-button start,
occupant classification system
37 ETCS 10
Multiport fuel injection system, sequential
multiport fuel system
38 ABS NO.2*
1
7. 5 VSC, ABS
39 EFI NO.1 7. 5
Multiport fuel injection system, sequential
multiport fuel system, electronic controlled
transmission
Fuse Ampere Circuit
