ES350_300h_OM_OM33A60U_(U)
727
6-3. Do-it-yourself maintenance
6
Maintenance and care
*
1
:Hybrid vehicles
*
2
: Gasoline vehicles
40
A/F*
2
20 Air intake system
EFI-MAIN
NO.2
*
1
20
Fuel system, air intake system, exhaust sys-
tem
41 AM2 7. 5
Power management system, smart access
system with push-button start
42 PA N E L 10
Switch illumination, audio system, multi-infor-
mation display, audio display, shift lever light,
glove box light, console box light,
Remote Touch, intuitive parking assist switch
illumination
43 DOME 7. 5
Clock, footwell lights, vanity lights, ornament
lights, personal lights, door courtesy lights,
outer foot lights
44 ECU-B NO.1 10
Smart access system with push-button start,
main body ECU, steering sensor, gauges and
meters, gateway ECU, electric tilt and tele-
scopic steering column, power seats, over-
head module, outside mirror control ECU,
power trunk opener and closer ECU
45 SPARE 25 Spare fuse
46 SPARE 30 Spare fuse
Fuse Ampere Circuit
