730
ES350_300h_OM_OM33A60U_(U)
6-3. Do-it-yourself maintenance
12 WIPER 25 Windshield wipers
13 BKUP LP 7. 5
Multiport fuel injection system, sequential
multiport fuel system, electronic controlled
transmission, audio system, navigation sys-
tem, back-up lights
14 FUEL OPN 10 Fuel filler door opener
15 EPS-IG1 10 Electric power steering
16 P/OUTLET RR 15 Power outlet
17 RADIO-ACC 5
Audio system, Remote Touch, multi-informa-
tion display, audio display, navigation system
18 S/HTR&FAN F/R 10 Seat heaters and ventilators
19 S/HTR&FAN F/L 10 Seat heaters and ventilators
20 OBD 7. 5 On-Board diagnosis system
21 ECU-B NO.2 10
Power window master switch, air condition-
ing system, smart access system with push-
button start, tire pressure warning system,
rear sunshade
22 STRG HTR 10 Heated steering wheel
23 PTL 25 Power trunk opener and closer ECU
24 STOP 7. 5
Power management system, multiport fuel
injection system, sequential multiport fuel
system, VSC, ABS, electronic controlled
transmission, driver support system, engine
room junction block assy, tail lights, high
mounted stoplight, smart access system with
push-button start, shift lock system
25 P/SEAT F/L 30 Power seats
26 A/C-B 7. 5 Air conditioning system
27 S/ROOF 10 Moon roof
28 P/SEAT F/R 30 Power seats
29 PSB 30 Pre-collision seat belt
30 D/L-AM1 20 Main body ECU, power door lock system
Fuse Ampere Circuit
