Lexus LS 430 - Page 12

LS 430 CMT - Dual band portable phone
42
2.6 Open the centre console.
Remove the rear duct by gently lifting
upwards.
: Clip (2x)
104
4
2.7 Remove the control switch panel
from the vehicle as shown.
: Connector (1x)
: Clip (2x)
108
32
5
2.8 Remove the centre console shifter cov-
ers and .
: Connector (1x)
: Clip (4x)
108
40
7
6
104
4
108
32
5
7
108
40
6
