Lexus LS 430 - Page 13

LS 430 CMT - Dual band portable phone
43
2.9 Remove the centre console cup holder
.
: Screw (2x)
109
8
2.10 Disconnect the two 2P centre console
wire harness connectors .
9
2.11 Remove the bolts and screw from the
lower console box .
: Bolt (4x)
: Screw (1x)
109
105
10
109
8
9
109
105
10
