4 Pull the cover as shown in the illustration to
disengage the 8 claws, starting from the claw
in the upper right corner and pull the cover
toward the front of the vehicle to remove it.
5 Disengage the 4 center claws from the filter.
6
Disengage the claws in the order of and
to remove the filter from the cover.
7 Remove the dust and clogs from the filter
using a vacuum cleaner, etc.
Make sure to also remove the dust and clogs
from the inner side of the air intake vent cover.
8 Engage the claws in the order of
and .
8-2. Cleaning and protecting the vehicle interior
599
8
Maintenance and care
