LEYBOLD MAG W 2010 C User Manual

Plug-in control
45
GA 05.139/1.02 - 06/99
T - 5 K
T - 2 K
T + 2 K
T + 5 K
2)
2)
T + 15 K
1)
1 2
3
2 3
4
3 2 2 133
4 455
Sollwert TMS
TMS Code
Heizung EIN
Kühlung EIN
TMS OK
Warnung TMS
Störung TMS
1) The TMS status code is displayed on the operation display; see Section 4.
2) Heater or cooling active
Fig. 36 Function diagram TMS for the MAG.DRIVE 2000
Setpoint temp. T
TMS Code
Heater ON
Cooling ON
TMS ok
Warning Temp. TMS
Failure TMS 5
