Description
1.7 Ordering data
Order No.
MAG W 2010 CHT 121 31
Seal Kit DN 250 standard 200 91 641
Seal Kit DN 250 metal 200 07 901
MAG.DRIVE 2000 converter 121 35
MAG.DRIVE 2000 converter (AMAT part no.) 121 44
Plug-in control 121 36
MAG.DRIVE 2000 with DeviceNet 121 37
Connecting cables, converter — pump see Fig.5
19“ installation frame 161 00
Connector for hardware interface
from 25 pins to 50 pins on request
Purge/vent valve 121 33
8
GA 05.139/1.02 - 06/99
Technical data
(continued)
MAG.DRIVE
Voltage range 200 - 240 V +10% -15%
Line supply frequency 50 / 60 Hz
Load
Stand-by approx. 100 W
Continuous (rated speed) 810 W
Maximum 1800 W
Max. voltage motor 60 V
Maximum pump current 20 A rms
Continuous pump current, max. 15 A rms
Maximum frequency 480 Hz
Load capability, relay output 42 V, 1 A
Temperature during operation 0-45° C
Storage temperature - 10° C to + 60° C
Relative air humidity Class F acc. to DIN 400 40
Overvoltage category II
Contamination level 2
in accordance with EN 61010
Weight 10 kg
The units have degree of protection IP20 in accordance
with EN 60529
(protection against the ingress of solid foreign bodies >
12 mm diameter (finger). It is not protected against the
ingress of water with damaging effects.)
An increased degree of protection, e.g. IP54 can only be
implemented by mounting the converter in an additional
housing.
