Installation
13
GA 05.139/1.02 - 06/99
Warning
Unauthorized opening of the converter
voids the warranty.
Before opening the converter, always dis-
connect it from the mains and the pump!
Before disconnecting any cables make sure
that the converter is switched off and the
pump has come to a standstill.
When applying external voltage in excess
of 42 V to terminals of the device, observe
local safety regulations!
Unauthorized device conversion and modi-
fications are prohibited for safety reasons.
Please keep this Operating Instruction for future referen-
ce.
2.2 Unpacking - storing -
transportation
Remove the equipment from the transportation box and
keep the packaging. Make sure that the product has not
been damaged during transportation. If this unit is dama-
ged contact your carrier and inform LEYBOLD if neces-
sary. For storage of the product, use the packaging pro-
vided.
Lift the pump by the crane eyelets or move it with at least
two persons.
You can position the pump on the base plate for trans-
port with a lift-truck. Protect the pump against slipping
and tipping over.
Caution
Be careful not to damage the sockets and
coolant connections during transportation.
Do not stand below the pump while connecting or remo-
ving the MAG.
The MAG is shipped in a sealed PE bag with desiccant.
Do not open the sealed package until immediately befo-
re installing.
Do not remove the covers and blanking flanges until you
are ready to make the connections, to ensure that the
MAG is installed under the cleanest possible conditions.
2 Installation
2.1
General safety information
Warning
Indicates procedures that must be strictly observed to
prevent hazards to persons.
Caution
Indicates procedures that must be strictly observed to
prevent damage to, or destruction of the MAG.
Warning
Never expose any parts of the body to the
vacuum.
Warning
The converter has dangerous voltage
levels.
Failure to strictly follow the instructions in
this Manual can result in death, severe
bodily injuries or significant material dama-
ge.
Only suitably qualified personnel are per-
mitted to work on the pump or converter.
Personnel must be completely knowledgea-
ble of all warning information and measures
which are specified in this Instruction
manual for transporting, installing, and ope-
rating the unit.
Qualified personnel
Qualified electrical personnel in this instruction manual
means a person who has received electrical engineering
instruction or is an electrical expert in accordance with
EN 60204, Part 1, 3.30 respectivly 3.55.
Warning
The device contains electrostatically sensi-
tive devices (ESD)!
