LEYBOLD MAG W 2010 C User Manual

GA 05.139/1.02 - 06/99
Description
6
1.6 Technical data
MAG W 2010 CHT
Pumping speed for N
2
measured
with splinter guard (PNEUROP) 1650 l·s
-1
Gas flow (continuous operation
with Argon) 1300 sccm
Compression for N
2
>10
8
Ultimate pressure as to DIN 28 400 < 10
-8
mbar
Max. forevacuum pressure
with Nitrogen 3.5 mbar
with Argon 4.3 mbar
Rotor Speed 28,800 min
-1
Run-up time < 8 min
Braking time with/without venting 1 / < 7.5 min
Cooling water
Cooling connection,
Swagelok tube OD 1/4“
Cooling water temperature 10 to 30 °C
50 to 86 °F
Inlet pressure 2 to 6 bar (absolute)
(i.e. 1 to 5 bar over atmosphere)
Base flange temperature 30 to 62 °C
(controlled) 86 to 144 °F
Weight approx. 65 kg
High-vacuum connection flange DN 250 ISO-F
Max. high-vacuum flange temperature 85 °C
185 °F
Forevacuum connection flange DN 40 KF
Recommended backing pump DRYVAC 50
Admissible ambient temperature 5 to 40 °C
40 to 104 °F
Storage temperature -10 to +60 °C
14 to 140 °F
Max. relative air humidity 95%
(non-condensing)
Degree of protection IP 20
(EN 60529)
Purge Gas
Purge gas: dry nitrogen, argon or similar
Purge gas throughput 0.5 to 0.65 mbar·l·s
-1
30 to 40 sccm
Connection: VCR Nut 1/4“
1.5 Standard specification
MAG
The turbomolecular pumps are shipped complete,
sealed in a PE bag containing a desiccant.
The maximum effective life time of the desiccant is one
year.
The intake flange is sealed with a transport seal, the
forevacuum flange with a plastic cap.
For the intake flange, a centering ring with FPM O-ring,
outer ring, and a splinter guard are enclosed.
We also provide the bolts for attaching the pump to your
tool. To avoid any safety risk we highly recommend using
only the bolts provided with the pump. Refer also to Sec-
tion 2.4 „Connecting the MAG ...“.
The electronic frequency converter MAG DRIVE as well
as the cables required for operation must be ordered
seperately.
In addition, a seal kit is included to seal the pump tightly
if it is removed from the process.
MAG.DRIVE
• Converter
• Line supply cable with USA connector, approx. 3m
• Line supply cable with EURO connector, approx. 3 m
• 2 spare fuses for the TMS (miniature fuses 5 x 20
mm, F4A; according to IEC 127-2/1) and 2 fuse hol-
ders 6.3 x 30 mm
• Connector for control plug X14 (pins 47/48 bridged)
Cable Set
• BEARING cable
• DRIVE/TMS cable

LEYBOLD MAG W 2010 C Specifications

General

Brand	LEYBOLD
Model	MAG W 2010 C
Category	Water Pump
Language	English
