2211.. GGrreeeenn AAddjjuussttmmeenntt((CCoommmmaanndd::ww))
To adjust green in colour temperature.
Transmission [k][w][ ][Set ID][][Data][Cr]
Data Min:0 ~ Max:C8
*Refer to "Real data mapping 2" as shown below
Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x]
2222.. BBlluuee AAddjjuussttmmeenntt((CCoommmmaanndd::$$))
To adjust blue in colour temperature.
Transmission [k][$][ ][Set ID][ ][Data][Cr]
Data Min:0 ~ Max:C8
*Refer to "Real data mapping 2"as shown below
Acknowledgement [$][ ][Set ID][ ][OK/NG][Data][x]]
*Real data mapping 2
0 : -20
5 : -19
A : -18
5F: -1
64: 0
69: +1
C3 : +19
C8 : +20
2233.. PPIIPP IInnppuutt SSeelleecctt ((CCoommmmaanndd22::yy))
To select input source for sub picture in PIP/Twin picture
mode. You can also adjust input source for sub picture
using PIP INPUT button remote control.
Transmission [k][y][ ][Set ID][ ][Data][Cr]
Data 0: Digital Data 2: AV1
Data 1: Analogue Data 3: AV2
Acknowledgement [y][ ][Set ID][ ][OK/NG][Data][x]
2244.. IISSMM MMeetthhoodd ((CCoommmmaanndd22::pp))
(Only 42PC1D*/50PC1D*/60PC1D* models)
To control the ISM method. You can also adjust ISM
method in Special menu.
Transmission [ j ][p][ ][Set ID][ ][Data][Cr]
Data 0: Normal Data 1: Orbiter
Data 2: Inversion Data 3: White Wash
Acknowledgement [p][ ][Set ID][ ][OK/NG][Data][x]
2255.. LLooww PPoowweerr ((CCoommmmaanndd22::qq))
(Only 42PC1D*/50PC1D*/60PC1D* models)
To reduce the power consumption of the set. You can
also adjust Low power in Special menu.
Transmission [ j ][q][ ][Set ID][ ][Data][Cr]
Data 0: low power off
1: low power on
Acknowledgement [q][ ][Set ID][ ][OK/NG][Data][x]
2266.. OOrrbbiitteerr TTiimmee SSeettttiinngg ((CCoommmmaanndd22::rr))
(Only 42PC1D*/50PC1D*/60PC1D* models)
To adjust orbiter operation time term.
Transmission [ j ][r][ ][Set ID][ ][Data][Cr]
Data Min: 1~ Max: FE(*transmit by Hexadecimal code),
Unit: Second
*Refer to ‘Real data mapping1’. See page 89.
Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x]
2277.. OOrrbbiitteerr PPiixxeell SSeettttiinngg ((CCoommmmaanndd22::ss))
(Only 42PC1D*/50PC1D*/60PC1D* models)
To adjust pixel number in orbiter function.
Transmission [ j ][s][ ][Set ID][ ][Data][Cr]
Data Min: 1~ Max: 3
*Refer to ‘Real data mapping1’. See page 89.
Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x]
2288.. CChhaannnneell TTuunniinngg ((CCoommmmaanndd:: mm aa))
To tune channel to following programme number
Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1]
[ ][Data2][Cr]
Data 0: High channel data
Data 1: Low channel data
Data 2: 00: Analogue TV Main
: 01: Analogue TV Sub
: 10: Digital Main
: 11: Digital Sub
ex) Analogue TV Main: ma 0 00 01 00
Digital Sub: ma 0 00 0A 11
* Channel Data Range:
Analogue TV: 0 ~ 63
Digital TV: 0 ~ 3E7
