APPENDIX
92
APPENDIX
2299.. SSeenndd IIRR CCooddee ((CCoommmmaanndd:: mm cc))
To send IR remote key code
Transmission [m][c][ ][Set ID][ ][Data][Cr]
Data Key code: Refer to page 94.
Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x]
* In this function, It’s unavailable to use the IR Code “08
(Power)” and C4 (Power On)”.
3300.. IInnppuutt SSeelleecctt((CCoommmmaanndd:: xx bb)) ((MMaaiinn PPiiccttuurree IInnppuutt))
To select input source for main picture.
Transmission [x][b][ ][Set ID][ ][Data][Cr]
Data 00 : Digital Data 41 : Component2
Data 10 : Analogue Data 50 : RGB-DTV
Data 20 : AV1 Data 60 : RGB-PC
Data 21 : AV2 Data 90 : HDMI/DVI
Data 40 : Component1
Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]
3311.. PPIIPP IInnppuutt SSeelleecctt((CCoommmmaanndd:: xx yy))
To select the input source for sub picture in PIP mode.
Transmission [x][y][ ][Set ID][ ][Data][Cr]
Data 00 : Digital
Data 10 : Analogue
Data 20 : AV1
Data 21 : Av2
Acknowledgement [y][][Set ID][ ][OK/NG][Data][x]
