48
206-4281
(Continued from previous page)
Note: To remove an individual item from the FTG Configuration List or the TV Setup Menu List, click on/
highlight the item to be removed, and then click the Remove Item button directly above the applicable
“List” window. To clear both the current FTG Configuration List and TV Setup Menu List contents, click the
Clear button in the List command section of the FTG File Manager main screen.
Note: To clear the current TLX File Contents, click the New button in the TLX File command section of
the FTG File Manager main screen (above the TLX File Contents window).
3. To add an FTG Channel Map to the FTG Configuration List, click under FTG Channel Map. This
will copy the current mapped channels to the FTG Configuration List.
Note: If you make any change(s) in the FTG Channel Map Configuration Utility to the current data to
be included in the FTG Configuration List, you will need to recopy the FTG Channel Map to the FTG
Configuration List.
4. (Optional) Load default FTG Installer Menu settings for the TV. In the Installer Menu Templates section
of the FTG File Manager main screen:
• If it is not already selected, click the down arrow at the right of the Region eld, and select North
America. Then, click the down arrow at the right of the Chassis eld, and select the appropriate
chassis (depending on the TV type) from the drop-down list of available models.
• Click the Load button.
• Use the FTG Installer Menu Conguration Utility to modify settings, if necessary. Then, return to the
FTG File Manager main screen.
5. If you wish to change the Zone assignment for the current FTG Installer Menu settings, click on the
down arrow at the right of the Zone eld (below the FTG Installer Menu Settings eld), and select the
appropriate Zone (0–8). See Reference section, “Using the TV Zoning Feature,” for further information
on the TV Zoning feature and setting the TV Zone # in the TV(s).
6. To add FTG Installer Menu settings to the FTG Configuration List, click under FTG Installer Menu
Settings. This will copy the selected model’s settings to the FTG Conguration List.
Note: If you make any change(s) in the FTG Installer Menu Configuration Utility to the current data to
be included in the FTG Configuration List, you will need to recopy the FTG Installer Menu settings to
the FTG Configuration List.
Note: Above both the FTG Conguration List and TV Setup Menu List windows, an Edit Zone eld
enables you to change the Zone assignment for each LX570M Installer Menu and/or TV Setup Menu
prole, if desired. Select/highlight the desired prole, and then click on the down arrow at the right of
the applicable Edit Zone eld to select the appropriate Zone.
7. Click the Save button in the List command section of the FTG File Manager main screen to save the
FTG Configuration List and, if present, TV Setup Menu List contents to an FTG Configuration (.tlx) file
on the PC’s hard drive for later use.
In the Save As pop-up window, name the file (avoid using special characters, such as ?, &, @, etc.)
and click Save. The default folder path is C:\Program Files\Zenith\FTG\TLX. Note that the FTG
Configuration file will have a “.tlx” file extension.
Note: To remove an individual item from the FTG Conguration List or the TV Setup Menu List before
saving the new le, click on/highlight the item to be removed, and then click the Remove Item button
directly above the applicable window. To clear both the current FTG Conguration List and TV Setup Menu
List contents, click the Clear button in the List command section of the FTG File Manager main screen.
8. Transfer the FTG Configuration (.tlx) file to a USB memory device, and proceed to “Importing a Clone
File” on pages 44 to 46 to transfer the FTG Configuration file to an LX570M TV.
FTG File Manager Utilities Overview (Cont.)
To Next Page
