LG 32LX570M Commercial Mode Setup Guide

57
206-4281
Reference: b-LAN Setup & Overview
A b-LAN enabled head end device, such as an LG FMA-LG101, broadcasts over the RF distribution system
to communicate to multiple TVs. When the TV is first installed, it must be turned ON in order for its embedded
b-LAN module to receive communication from the head end device. At this point, if it is desired for the b-LAN
module to always be powered, including while the TV is turned OFF, set Installer Menu item 118 POWER
SAVINGS to 1.
Also, if MPI communication is required for external MPI control, set Installer Menu item 118 POWER SAVINGS
to 1 so that the GAME CONTROL/MPI port circuitry is always powered.
Caution: POWER SAVINGS should NEVER be set to 7. This setting is intended for factory use
only.
The b-LAN module is internal to the TV. It allows hotel/institution head end equipment with b-LAN technology
to communicate, via the institution’s RF distribution system, with the TV for configuration and control.
Installer Menu item 118 POWER SAVINGS controls the power circuitry for both the embedded b-LAN module
and the GAME CONTROL/MPI port. The default value is 3—the b-LAN module is only powered when the TV
is turned ON. See chart below.
POWER
SAVINGS
1 On On
3 (default) Off On
TV ON
TV OFF
b-LAN & GAME
CONTROL/MPI Port
Power
b-LAN & GAME
CONTROL/MPI Port
Power

LG 32LX570M Specifications

General

Screen shape	Flat
Response time	9 ms
Display diagonal	31.8 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1200:1
Display diagonal (metric)	81.28 cm
Screen format adjustments	4:3, 16:9
Supported graphics resolutions	1366 x 768
Motion interpolation technology	-
3D	No
Cable lock slot type	Kensington
RJ-12 ports quantity	1
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Smart modes	Cinema, Energy saving, Game, Sports, Standard, Vivid
Sound modes	Game, Movie, Music, News, Sports, Standard
Audio decoders	Dolby Digital
RMS rated power	10 W
Number of speakers	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Audio formats supported	AAC, AC3, EAC3, MP3, PCM
Image formats supported	JPG
Picture processing technology	LG Triple XD Engine
Panel mounting interface	200 x 200 mm
AC input voltage	120 V
Power consumption (standby)	0.5 W
Power consumption (typical)	42 W
Package depth	114.3 mm
Package width	800.1 mm
Package height	510.54 mm
Package weight	6622.45 g
Certification	UL, FCC, cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (without stand)	55.88 mm
Width (without stand)	734.06 mm
Height (without stand)	436.88 mm
Weight (without stand)	5307.03 g
