LG 32LX570M Commercial Mode Setup Guide

60
206-4281
Reference: LX570M Hospital Operations
Hospital Features
The following table identies when and how the LX570M hospital features are supported in three different
TV congurations. As indicated in the introduction to this document, LG commercial TV functionality is based
on “ownership” of the Channel Map. For the purposes of this table, “CPU” indicates that the TV is in Pass-
through Mode with the Channel Map in the CPU (i.e., auto-tuned/edited channel lineup) and “PTC” indicates
that the TV is in Pass-through Mode with the Channel Map in the PTC (PTC-CTV Mode).
CPU
PTC FTG/PPV Mode
Hospital Mode State Disabled Enabled Disabled Enabled Disabled Enabled
Installer Menu Item
IR Banks Enable 012 X
Scan Mode 013 X X X* X*
Start Channel in Scan Mode 014 X X X* X*
Feature Level 020
Bed 1/Bed 2 020 X X X
Multi-code IR 020 X X X X X X
Speaker 020 X X X
Function Preview 025 X X
Hospital Mode 027
Bed 1/Bed 2 027 X X X
Pillow Speaker Voltage 027 (b) X (b) X (b) X
Speaker 027 X X X
Quick Shutoff 077 (c) (c) (c) (c) (c) (c)
Channel Banks
Number of Banks Enabled 1 4 1 4*
Channel Preview/Banks Setup Menu X X
Blanked Channel X X X X
Inactive TV X X*
SAP Key (special use in Channel
Preview/Banks Setup Menu)
X X*
Aux Input Sources
Input List Menu X X X X
Aux in Channel Lineup X X (d) X*/(d)
TV Setup Menus
Audio (TV Speaker) (e) (e) (e) (e)
Option (Power Indicator) X X X X
* Applicable for FTG Mode via CPU only.
X = feature supported
a) Turn ON function only. Always goes to channel 2-0.
b) Defaults to Zenith pillow speaker code/(+12v) supply voltage.
c) Quick Shutoff feature only functions when Scan Mode is enabled and if you are using an analog pillow speaker.
d) Dependent upon installer-dened FTG/PPV Channel Map.
e) Audio Menu is only accessible when the speaker selected is TV Only or both TV & Pillow.

LG 32LX570M Specifications

General

Screen shape	Flat
Response time	9 ms
Display diagonal	31.8 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1200:1
Display diagonal (metric)	81.28 cm
Screen format adjustments	4:3, 16:9
Supported graphics resolutions	1366 x 768
Motion interpolation technology	-
3D	No
Cable lock slot type	Kensington
RJ-12 ports quantity	1
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Smart modes	Cinema, Energy saving, Game, Sports, Standard, Vivid
Sound modes	Game, Movie, Music, News, Sports, Standard
Audio decoders	Dolby Digital
RMS rated power	10 W
Number of speakers	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Audio formats supported	AAC, AC3, EAC3, MP3, PCM
Image formats supported	JPG
Picture processing technology	LG Triple XD Engine
Panel mounting interface	200 x 200 mm
AC input voltage	120 V
Power consumption (standby)	0.5 W
Power consumption (typical)	42 W
Package depth	114.3 mm
Package width	800.1 mm
Package height	510.54 mm
Package weight	6622.45 g
Certification	UL, FCC, cUL, NOM
Sustainability certificates	RoHS, ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (without stand)	55.88 mm
Width (without stand)	734.06 mm
Height (without stand)	436.88 mm
Weight (without stand)	5307.03 g
