ENGLISH
32
PRODUCT SPECIFICATION
PRODUCT SPECIFICATION
34UC87
34UC87M
LCD Screen Type TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Screen
Color Depth HDMI 8-bit color is supported.
DP (DisplayPort) 10-bit color is supported.
Thunderbolt ( )
8-bit color is supported.
Pixel Pitch 0.2325 mm x 0.2325 mm
Resolution HDMI Max Resolution 3440 x 1440 @ 50 Hz
Recommended Resolution 3440 x 1440 @ 50 Hz
DP (DisplayPort)
Thunderbolt ( )
Max Resolution 3440 x 1440 @ 60 Hz
Recommended Resolution 3440 x 1440 @ 60 Hz
Video Signal Horizontal Frequency 30 kHz to 90 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Separate Sync.
Input Connector
34UC87
H/P OUT, HDMI IN 1, HDMI IN 2, DP (DisplayPort) IN, Thunderbolt ( ),
USB UP, USB IN 1, 2
34UC87M
H/P OUT, HDMI IN 1, HDMI IN 2, DP (DisplayPort) IN, Thunderbolt ( ),
USB UP, USB IN 1, 2, IR IN, IR OUT
Power Sources Power Rating 19 V 6.0 A
Power Consumption
(Typical)
Operating Mode: 80 W (Typical, USB excluded) (Outgoing condi-
tion)
Sleep Mode ≤ 1.2 W
Off Mode ≤ 0.5 W
Off Mode ≤ 0.3 W (DC switch is off.)
AC/DC Adapter LCAP31 type, manufactured by Lienchang
Output: 19 V 7.37 A
Stand Angle Forward/Backward: -5° to 15° (Head)
Environmental
Conditions
Operating Conditions Temperature 0°C to 40°C (32 °F to 104°F)
Humidity Less than 80%
Storing Conditions Temperature -20°C to 60°C (-4 °F to 140°F)
Humidity Less than 85%
Audio Output 7 W + 7 W
Supported
Operating System
Win 7, Win 8.1, Mac OS*
Dimensions Monitor Size (Width x Height x Depth)
With Stand 830.5 mm x 460.8 mm x 241.4 mm
(32.6 inch x 18.1 inch x 9.5 inch)
Without Stand 830.5 mm x 370.3 mm x 79.8 mm
(32.6 inch x 14.5 inch x 3.1 inch)
Weight (Without
Packaging)
With Stand 10.0 kg (22.0 Ib)
Without Stand 8.0 kg (17.6 Ib)
Specifications are subject to change without notice.
* Mac products may not support the recommended resolution or some features.
(For more information, refer to the support information card of Mac which is provided separately.)
