DISASSEMBLY
1. Preparation
1.1. Preparation tool (jig)
1.2. Preparation tool (Curved PAD)
2. Stand Assembly Separation
1) Lay the set by the Curved PAD in Box
2) Disassemble the Stand after pull the button to down
3) Disassemble the Thumb Screw
4) Remove the Screw (4ea).
5) Disassemble the Back Cover (By using JIG)
To Next Page
