2. Signal Timing (Resolution)
2.1. Signal (Video & Sync)
2.2. H/V Timing
mode section polarity
DOT
CLOCK
[MHz]
Frequency
[kHz]/[Hz]
Total
Period
(E)
Display
(A)
Front
Porch
(D)
Sync.
(C)
Back
Porch(B)
Resolution
1
H(Pixels)
-
25.175
31.469 800 640 16 96 48
640 x 480
V(Lines)
- 59.94 525 480 10 2 33
2
H(Pixels)
+
40.0
37.879 1056 800 40 128 88
800 x 600
V(Lines)
+ 60.317 628 600 1 4 23
3
H(Pixels)
-
65.0
48.363 1344 1024 24 136 160
1024 x 768
V(Lines)
- 60.0 806 768 3 6 29
4
H(Pixels)
+
79.99
54.347 1472 1152 32 96 192
1152 x 864
V(Lines)
+ 60.05 905 864 1 3 37
5
H(Pixels)
+
74.25
45 1650 1280 110 40 220
1280 x 720
V(Lines)
+ 60 750 720 5 5 20
6
H(Pixels)
-
83.5
49.702 1680 1280 72 128 200
1280 x 800
V(Lines)
+ 59.810 831 800 3 6 22
7
H(Pixels)
+
108.0
63.981 1688 1280 48 112 248
1280 x 1024
V(Lines)
+ 60.02 1066 1024 1 3 38
8
H(Pixels)
-
146.25
60.00 1800 1600 24 80 96
1600 x 900
V(Lines)
+ 60.00 1000 900 1 3 96
9
H(Pixels)
+
148.50
65.29 2240 1680 104 176 280
1680 x 1050
V(Lines)
- 59.954 1089 1050 3 6 30
10
H(Pixels)
+
174.50
67.50 2200 1920 88 44 148
1920 x 1080
V(Lines)
- 60 1125 1080 4 5 36
11
H(Pixels)
+
194.75
48.688 4000 3840 48 32 80
3840 x 1600
V(Lines) -
29.998 1623 1600 3 10 10
12
H(Pixels)
+
327.50
81.875 4000 3840 48 32 80
3840 x 1600
V(Lines)
- 49.985 1638 1600 3 10 25
13
(2)
H(Pixels)
+
395.00
98.75 4000 3840 48 32 80
3840 x1600
V(Lines) -
59.994 1646 1600 3 10 33
