LG 50PG2000 User Manual

111
APPENDIX
01. Power k a 00 ~ 01
02. Aspect Ratio k c Refer to p. 112
03. Screen Mute k d 00 ~ 01
04. Volume Mute k e 00 ~ 01
05. Volume Control k f 00 ~ 64
06. Contrast k g 00 ~ 64
07. Brightness k h 00 ~ 64
08. Colour k i 00 ~ 64
09. Tint k j 00 ~ 64
10. Sharpness k k 00 ~ 64
11. OSD Select k l 00 ~ 01
12.
Remote control lock mode
k m 00 ~ 01
13. Balance k t 00 ~ 64
14.
Colour Temperature k u 00 ~ 02
15. Abnormal Status k z 00 ~ 09
16.
ISM Method j p Refer to p. 114
17. Power Saving j q 00 ~ 04
18. Auto Configure j u 01
19. Equalize j v Refer to p. 114
20.
Tune Command m a Refer to p. 114
21.
Channel Add/Skip m b 00 ~ 01
22. Key m c Key Code
23. Control Back Light m g 00 ~ 64
24. Input select (Main) x b Refer to p. 115
Communication Parameters
A
Baud rate : 9600 bps
(
UART
)
A
Data length : 8 bits
A
Parity : None
A
Stop bit : 1 bit
A
Communication code : ASCII code
A
Use a crossed (reverse) cable.
Transmission
*
[Command 1] : First command to control the TV.
(j, k, m or x)
*
[Command 2] : Second command to control the TV.
*
[Set ID] : You can adjust the set ID to choose
desired monitor ID number in option
menu. Adjustment range is 1 ~ 99.
When selecting Set ID ‘0’, every
connected set is controlled.
Set ID is indicated as decimal (1~99)
on menu and as Hexa decimal
(0x0~0x63) on transmission/
receiving protocol.
*
[DATA] : To transmit command data.
Transmit ‘FF’ data to read status of
command.
*
[Cr] : Carriage Return
ASCII code ‘0x0D’
*
[ ] : ASCII code ‘space (0x20)’
[Command1][Command2][ ][Set ID][ ][Data][Cr]
OK Acknowledgement
* The TV transmits ACK (acknowledgement) based on
this format when receiving normal data. At this time, if
the data is data read mode, it indicates present status
data. If the data is data write mode, it returns the data
of the PC computer.
[Command2][ ][Set ID][ ][OK][Data][x]
Error Acknowledgement
* The TV transmits ACK (acknowledgement) based on
this format when receiving abnormal data from
nonviable functions or communication errors.
[Command2][ ][Set ID][ ][NG][Data][x]
Transmission / Receiving ProtocolCommand Reference List
*
When setting the 15 ~ 24, a menu does not appear on screen.
COMMAND
1
COMMAND
2
DATA
(Hexadecimal)
