ENGLISH
24
MAKING CONNECTIONS
ARC (Audio Return Channel)
When connected with a high-speed HDMI cable, digital audio can be sent to a compatible device without an additional
optical audio cable.
ARC is only supported on the
HDMI (4K @ 60 Hz) / DVI IN 2 (ARC)
port. An external audio device that supports ARC should
be connected to
HDMI (4K @ 60 Hz) / DVI IN 2 (ARC)
if you wish to use ARC.
HDMI
DVD / Blu-Ray / HD Cable Box / HD STB
(*Not Provided)
(For 77EG970T)
4K @ 50/60 Hz Support Format
Resolution
Frame
rate
(Hz)
Color Depth / Chroma Sampling
8 bit 10 bit 12 bit
3840 X 2160p
4096 X 2160p
50.00
59.94
60.00
YCbCr
4:2:0
YCbCr 4:2:0
1
YCbCr 4:2:2
1
YCbCr
4:4:4
1
- -
RGB
4:4:4
1
- -
1 Supported at HDMI IN 3 Port only
HDMI specifications may be different for each input port,
so make sure to check the device specifications before
connecting.
Contact customer service for more information on the
HDMI specifications of each input port.
NOTE
