ENGLISH
37
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement
AC 100 - 240 V~ 50 / 60 Hz
Television System
NTSC, PAL-M/N, DVB-T, DVB-T2
Program Coverage
VHF 2-13, UHF 14-69, DTV 2-69, CATV 1-125
External Antenna Impedance
75
Ω
Environment
condition
Operating temperature 0 to 40 °C
Operating humidity Less than 80 %
Storage temperature -20 to 60 °C
Storage humidity Less than 85 %
MODELS
55EC930T
(55EC930T-DA)
Dimensions
(W x H x T) (D)
With stand (mm) 1,225 x 753 x 204
Without stand (mm) 1,225 x 715 x 44 (81)
Weight
With stand (kg) 16.7
Without stand (kg) 14.7
Current value / Power consumption 3.2 A / 320 W
MODELS
77EG970T
(77EG970T-DA)
Dimensions
(W x H x T) (D)
With stand (mm) 1,718 x 1,110 x 322
Without stand (mm) 1,718 x 1,064 x 34.7 (108.2)
Weight
With stand (kg) 43.3
Without stand (kg) 39.9
Current value / Power consumption 5.9 A / 590 W
(For 55EC930T)
Wireless module (LGSBW41) Specifications
Wireless Lan Bluetooth
Standard
IEEE 802.11a/b/g/n
Standard
Bluetooth Version 3.0
Frequency Range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Frequency Range
2400 to 2483.5 MHz
Output Power (Max.)
802.11a: 11.5 dBm
802.11b: 11 dBm
802.11g: 10.5 dBm
802.11n - 2.4 GHz: 11 dBm
802.11n - 5 GHz: 12.5 dBm
Output Power (Max.)
10 dBm or Lower
Because band channel used by the country could be different, the user can not change or adjust the operating frequency and this
product is set for the regional frequency table.
This device should be installed and operated with minimum distance 20 cm between the device and your body. And this phrase is for
the general statement for consideration of user environment.
Contains FCC ID: BEJLGSBW41 / Contains IC: 2703H-LGSBW41
Depth
Thickness
