ASSEMBLING AND PREPARING
Composite gender cable
(See p.25)
Cinema 3D Glasses
The number of 3D glasses
may differ depending on the
model or country.
(Only UB83**)
NOTE
y
The items supplied with your product may vary depending on the model.
y
Product specications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
y
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
thick and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not t into your TV’s USB port.
A
B
A
B
*A
=
10 mm
*B
=
18 mm
How to use the ferrite core (Depending on model)
y
Use the ferrite core to reduce the electromagnetic interference in the LAN cable. Wind the LAN
cable once on the ferrite core. Place the ferrite core close to the TV.
[Cross Section of Ferrite Core]
[to the TV] [to an External device]
To Next Page
