26
ENG
ENGLISH
MAKING CONNECTIONS
Audio connection
You may use an optional external audio system
instead of the built-in speaker.
Digital optical audio connection
Transmits a digital audio signal from the TV
to an external device. Connect the external
device and the TV with the optical audio cable
as shown.
OPTICAL
AUDIO IN
(*Not Provided)
Digital Audio System
NOTE
y
Do not look into the optical output port.
Looking at the laser beam may damage
your vision.
y
Audio with ACP (Audio Copy Protection)
function may block digital audio output.
Headphone connection
Transmits the headphone signal from the TV to
an external device. Connect the external device
and the TV with the headphone as shown.
EXT
(*Not Provided)
NOTE
y
AUDIO
menu items are disabled when
connecting a headphone.
y
OPTICAL DIGITAL AUDIO OUT is not
available when connecting a headphone.
y
Headphone impedance: 16 Ω
y
Max audio output of headphone: 0.627
mW to 1.334 mW
y
Headphone jack size: 0.35 cm
To Next Page
