5.2.2. PC mode
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed Remarks
1 640*350 @70Hz 31.468 70.09 25.17 EGA
2 720*400@70Hz 31.469 70.08 28.32 DOS
3 640*480@60Hz 31.469 59.94 25.17 VESA(VGA)
4 800*600 @60Hz 37.879 60.31 40 VESA(SVGA)
5 1024*768 @60Hz 48.363 60.00 65 VESA(XGA)
6 1152*864@60Hz 54.348 60.053 80 VESA
7 1280*1024 @60Hz 63.981 60.020 109.00 VESA(SXGA) Support to HDMI-PC
8 1360*768 @60Hz 47.712 60.015 85.5 VESA(WXGA)
9 1920*1080@60Hz 67.5 60 158.40 WUXGA(CEA 861D)
10 3840*2160@30Hz 67.5 30.00 297.00 UDTV 2160P Only UHD Model
11 3840*2160@25Hz 56.25 25.00 297.00 UDTV 2160P Only UHD Model
12 3840*2160@24Hz 54.0 24.00 297.00 UDTV 2160P Only UHD Model
13 4096*2160@30Hz 61.43 29.97 297.00 UDTV 2160P Only UHD Model
14 4096*2160@30Hz 67.5 30.00 297.00 UDTV 2160P Only UHD Model
15 4096*2160@25Hz 56.25 25.00 297.00 UDTV 2160P Only UHD Model
16 4096*2160@24Hz 53.95 23.97 297.00 UDTV 2160P Only UD Model, Port3
17 4096*2160@24Hz 54 24.00 297.00 UDTV 2160P Only UD Model, Port3
