5.2. HDMI : EDID DATA : Refer to adjust specification
5.2.1. DTV mode
No Resolution H-freq(kHz) V-freq.(Hz)
Pixel
clock(MHz)
Proposed Remark
1 640*480 31.469 59.94 25.125 SDTV 480P
2 640*480 31.5 60 25.125 SDTV 480P
3 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I) Spec. out but display
4 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
5 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz
6 720*480 31.47 59.94 27 SDTV 480P
7 720*480 31.5 60.00 27.027 SDTV 480P
8 720*576 31.25 50.00 27 SDTV 576P
9 1280*720 44.96 59.94 74.176 HDTV 720P
10 1280*720 45 60.00 74.25 HDTV 720P
11 1280*720 37.5 50.00 74.25 HDTV 720P
12 1920*1080 28.125 50.00 74.25 HDTV 1080I
13 1920*1080 33.72 59.94 74.176 HDTV 1080I
14 1920*1080 33.75 60.00 74.25 HDTV 1080I
15 1920*1080 26.97 23.976 63.296 HDTV 1080P
16 1920*1080 27.00 24.000 63.36 HDTV 1080P
17 1920*1080 28.125 25 74.25 HDTV 1080P
18 1920*1080 33.71 29.97 79.120 HDTV 1080P
19 1920*1080 33.75 30.00 79.20 HDTV 1080P
20 1920*1080 56.25 50.00 148.5 HDTV 1080P
21 1920*1080 67.432 59.94 148.350 HDTV 1080P
22 1920*1080 67.5 60 148.50 HDTV 1080P
23 3840*2160 53.95 23.98 297.00 UDTV 2160P Only UD Model
24 3840*2160 54 24.00 297.00 UDTV 2160P Only UD Model
25 3840*2160 56.25 25.00 297.00 UDTV 2160P Only UD Model
26 3840*2160 61.43 29.97 297.00 UDTV 2160P Only UD Model
27 3840*2160 67.5 30.00 297.00 UDTV 2160P Only UD Model
28 3840*2160 112.5 50 594 UDTV 2160P Only UD Model, Port3
29 3840*2160 135 60 594 UDTV 2160P Only UD Model, Port3
30 3840*2160 135 59.94 594 UDTV 2160P Only UD Model, Port3
31 4096*2160 53.95 23.98 297 UDTV 2160P Only UD Model
32 4096*2160 54 24.00 297 UDTV 2160P Only UD Model
33 4096*2160 56.25 25.00 297 UDTV 2160P Only UD Model
34 4096*2160 61.43 29.97 297 UDTV 2160P Only UD Model
35 4096*2160 67.5 30.00 297 UDTV 2160P Only UD Model
36 4096*2160 112.5 50.00 594 UDTV 2160P Only UD Model, Port3
37 4096*2160 135 60.00 594 UDTV 2160P Only UD Model, Port3
38 4096*2160 135 59.94 594 UDTV 2160P Only UD Model, Port3
