LG 65UB930T Service Manual

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4. General Specification
No Item Specication Remark
1. Display Screen Device 84” wide Color Display Module Resolution: 3840*2160
79” wide Color Display Module
55” wide Color Display Module
49” wide Color Display Module
2. Aspect Ratio 16:9 All
3. LCD Module 79" QWUXGA TFT LCD LC790EQF-FGF1
84” TFT WUXGA LCD LC840EQD-SGF1
55" QWUXGA TFT LCD LC550EQE-PGF2
49" QWUXGA TFT LCD LC490EQE-XGF2
4. Operating Environment TFT Temp. : 0 ~ 50 deg
Humidity : 10 ~ 90%
LGE SPEC
5. Storage Environment TFT Temp. : -20 ~ 60 deg
Humidity : 10 ~ 90%
Only 84” , LGD SPEC
Temp. : -20 ~ 60 deg
Humidity : 5 ~ 90%RH
LGE SPEC
6. Input Voltage AC100 ~ 240V, 50/60Hz
7. Power Consumption(Typ) T240
Advance
Cinema
79” 165.6 W
84” 402 W
T120
Advance
Cinema
55” 111.5 W
49” 97.1 W
8. LCD Module Size Maker Inch (H)mm × (V)mm × (D)mm
LGD 79” 1759.4 x 1002.4 x13.9
84” 1904.0 x 1096.0 x 15.5
49” 1086.3 x 623.8 x 10.6
55” 1226.0 x 702.1 x 9.2
Pixel Pitch Maker Inch mm x mm
LGD 79” 0.453 x 0.453
84” 0.4845x0.4845
49” 0.27963 x 0.27963
55” 0.315 x 0.315
Back Light LGD 49”/55”/
79”/84”
ULTRA HD
Display Colors 1.06 Billion Colors @ 10bit(D)
Coating Hard coating(2H), Anti-glare treatment

LG 65UB930T Specifications

General

Brand	LG
Model	65UB930T
Category	LED TV
Language	English
