6. 3D mode-DTV/HDMI/USB
6.1. RF Input (3D supported mode manually)
6.2. HDMI Input
6.2.1. RF Input (3D supported mode automatically)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed 3D input proposed mode
1 720*480 31.5 60 27.03 SDTV 480P 2D to 3D, Side by Side(Half),
Top & Bottom, Checker Board,
Frame Sequential, Row Interleaving,
Column Interleaving
2 720*576 31.25 50 27 SDTV 576P
3 1280*720 45.00 60.00 74.25 HDTV 720P
37.500 50 74.25 HDTV 720P
4 1920*1080 33.75 60.00 74.25 HDTV 1080I 2D to 3D, Side by Side(Half), Top & Bottom
28.125 50.00 74.25 HDTV 1080I
5 1920*1080 27.00 24.00 74.25 HDTV 1080P 2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board, Row Interleaving, Column
Interleaving
28.12 25 74.25 HDTV 1080P
33.75 30.00 74.25 HDTV 1080P
67.50 60.00 148.5 HDTV 1080P 2D to 3D, Side by Side(Half),
Top & Bottom,
Checker Board, Single Frame Sequential,
Row Interleaving, Column Interleaving
56.250 50 148.5 HDTV 1080P
6 3840*2160 53.95 23.976 297.00 HDTV 2160P 2D to 3D,
Top & Bottom(half), Side by Side(half),
54 24.00 296.703
56.25 25.00 297.00
61.43 29.970 297.00
67.5 30.00 296.703
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed 3D input proposed mode
1 1280*720 37.500 50 74.25 HDTV 720P 2D to 3D, Side by Side, Top & Bottom
2 1920*1080 28.125 50 74.25 HDTV 1080I 2D to 3D, Side by Side, Top & Bottom
