2 www.fairchildsemi.com
FSCQ-Series Rev. 1.1.2
FSCQ-Series Green Mode Fairchild Power Switch (FPS™)
Typical Circuit
Figure 1. Typical Flyback Application
Table 1. Maximum Output Power
Notes:
1. Maximum practical continuous power in an open frame design at 50 ° C ambient.
2. 230 VAC or 100/115 VAC with doubler.
3. The junction
t
emperature can limit the maximum output power.
Output Power Table
3
Product
230 VAC ± 15%
2
85–265 VAC
Open Frame
1
Open Frame
1
FSCQ0565RT 70W 60W
FSCQ0765RT 100W 85W
FSCQ0965RT 130W 110W
FSCQ1265RT 170W 140W
FSCQ1465RT 190W 160W
FSCQ1565RT 210W 170W
FSCQ1565RP 250W 210W
V
CC
GND
Drain
Sync
V
O
PWM
V
FB
AC
IN
FSCQ-Series
