Electrical System Installation
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Table 13: Electrical Data for 460V 3 Wire Heat Pump Chiller.
Chiller Electrical Data
ELECTRICAL
Specications
Tons Model No. Voltage (Hz) (PH)
Voltage Tolerance
(Min. ~ Max.)
Power Supply System
Independent
Circuits
MCA MFA MSC RLA
17 ACHH017VBAB 208-230 60 3 187-253 77.3 80 20.4 66.8 1
20 ACHH020VBAB 208-230 60 3 187-253 78.2 80 20.4 67.7 1
33 ACHH033VBAB 208-230 60 3 187-253 146.1 150 40.8 133.6 1
40 ACHH040VBAB 208-230 60 3 187-253 147.9 150 40.8 135.4 1
50 ACHH050VBAB 208-230 60 3 187-253 77.3 | 146.1 80 |150 20.4 | 40.8 66.8 | 133.6 2
60 ACHH060VBAB 208-230 60 3 187-253 78.2 | 147.9 80 |150 20.4 | 40.8 67.7 | 135.4 2
17 ACHH017HBAB 460 60 3 414-506 46.8 60 9.7 39.8 1
20 ACHH020HBAB 460 60 3 414-506 48 60 9.7 40.8 1
33 ACHH033HBAB 460 60 3 414-506 88.6 100 19.5 79.6 1
40 ACHH040HBAB 460 60 3 414-506 90.8 100 19.5 81.6 1
50 ACHH050HBAB 460 60 3 414-506 130.4 150 29.2 119.4 1
60 ACHH060HBAB 460 60 3 414-506 133.6 150 29.2 122.4 1
Voltage Range: Power supplied to the chiller must fall within the voltage minimum to
maximum range listed in the table above. The chiller will not operate normally if the power
supply voltage falls below or above the tolerance range.
Maximum allowable voltage variance permitted between phases is 2%.
MCA: Minimum Circuit Ampacity (A) (Criteria used to select the wiring standard).
MFA: Maximum Fuse Amps (A) (Criteria used to select circuit breaker and ground error
circuit breaker [electricity leakage circuit breaker]).
MSC: Maximum Start Current (A)
RLA: Rated Load Amps (A) (Current required when operating under the following
conditions—Cooling: Outdoor Air Temperature: 8°1F DB / 66°F WB; Water Inlet / Outlet
Temperature: 54°F / 44°F).
FLA: Full Load Amps (A).
