1. Specification
Specification
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. EEV : Electronic Expansion Valve
5. To be added for more available Models
Type
Model Unit
W
Cooling Capacity kcal/h
Btu/h
W
Heating Capacity kcal/h
Btu/h
Casing
Dimensions (W*D*H)
Body
mm
inch
Coil
Rows x Columns x FPI
Face Area m
2
Type
Motor Output x Number
W
Running Current A
Fan Air Flow Rate(H/M/L) cmm
cfm
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Liquid Side mm(inch)
Pipe Connections
Gas Side mm(inch)
Drain Pipe(Internal Dia.)
mm
Net Weight kg(lbs)
Noise Level
(Sound Press, 1m, H/M/L)
dBA±3
Power Supply Ø / V / Hz
Refrigerant Control
Power cable mm
2
Transmission cable mm
2
Floor Standing
ARNU07GCEA1 ARNU09GCEA1 ARNU12GCEA1 ARNU07GCEU1 ARNU09GCEU1 ARNU12GCEU1
2,200 2,800 3,600 2,200 2,800 3,600
1,900 2,400 3,100 1,900 2,400 3,100
7,500 9,600 12,300 7,500 9,600 12,300
2,500 3,200 4,000 2,500 3,200 4,000
2,200 2,800 3,400 2,200 2,800 3,400
8,500 10,900 13,600 8,500 10,900 13,600
Galvanized Galvanized Galvanized Galvanized Galvanized Galvanized
Steel Plate Steel Plate Steel Plate Steel Plate Steel Plate Steel Plate
1067x203x635 1067x203x635 1067x203x635 978x190x625 978x190x625 978x190x625
42.2x8.0x25.0 42.2x8.0x25.0 42.2x8.0x25.0 38.5x7.5x24.6 38.5x7.5x24.6 38.5x7.5x24.6
2x12x19 2x12x19 2x12x19 2x12x19 2x12x19 2x12x19
0.16 0.16 0.16 0.16 0.16 0.16
Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
30 30 30 30 30 30
0.1 0.1 0.1 0.1 0.1 0.1
8.5/7.5/6.5 9.5/8.5/7.5 10.5/9.5/8.5 8.5/7.5/6.5 9.5/8.5/7.5 10.5/9.5/8.5
300/265/229 335/300/265 371/335/300 300/265/229 335/300/265 371/335/300
Direct Direct Direct Direct Direct Direct
BLDC BLDC BLDC BLDC BLDC BLDC
Microprocessor, Microprocessor, Microprocessor, Microprocessor, Microprocessor, Microprocessor,
Thermostat for Thermostat for Thermostat for Thermostat for Thermostat for Thermostat for
cooling and heating cooling and heating cooling and heating cooling and heating cooling and heating cooling and heating
Foamed polystrene Foamed polystrene Foamed polystrene Foamed polystrene Foamed polystrene Foamed polystrene
Net(Washable) Net(Washable) Net(Washable) Net(Washable) Net(Washable) Net(Washable)
Fuse Fuse Fuse Fuse Fuse Fuse
Ø6.35(1/4) Ø6.35(1/4) Ø6.35(1/4) Ø6.35(1/4) Ø6.35(1/4) Ø6.35(1/4)
Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2)
12 12 12 12 12 12
27(59.5) 27(59.5) 27(59.5) 19(41.9) 19(41.9) 19(41.9)
35/33/31 36/34/32 37/35/33 35/33/31 36/34/32 37/35/33
1, 220 ~ 240, 50 1, 220 ~ 240, 50 1, 220 ~ 240, 50 1, 220 ~ 240, 50 1, 220 ~ 240, 50 1, 220 ~ 240, 50
1, 220, 60 1, 220, 60 1, 220, 60 1, 220, 60 1, 220, 60 1, 220, 60
EEV EEV EEV EEV EEV EEV
CV2.0 X 3C CV2.0 X 3C CV2.0 X 3C CV2.0 X 3C CV2.0 X 3C CV2.0 X 3C
CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C
