4. Dimensions
Dimensions
ARNU09GTE*1
ARNU12GTE*1
ARNU18GTE*1
269
670
30
570
269
90 90
120.4
30
521
670
570
450
40
110 110
670
670
4
1
3
2
5
6
Unit:mm
570 Unit size
570 Unit size
450 (Hanging bolt)
7575
600 (Ceiling opening)
600 (Ceiling opening)
521(Hanging bolt)
39.5
39.5
(unit : mm)
Number Name Descripition
1 Liquid pipe connection
Unit size(9k, 12k, 18k):Ø6.35
2 Gas pipe connection
Unit size(9k, 12k, 18k):Ø12.7
3 Drain pipe connection
4 Power supply connection
5 Air discharge grill
6 Air suction grill
