INTRODUCTION
13
ENGLISH
* The feature can be changed according to type of model.
(Other) Manual
NOTE
• When mechanical connectors are reused indoors, sealing parts shall be renewed.
Front grille
Air filter
On/Off button
Signal receiver
Display
Plasmaster Ionizer
Air deflector
(Vertical louver & Horizontal vane)
Air outlet
[Wall Mounted]
Name Quantity Shape
Installation plate 1 EA
Cloth tape
Connector
1 EA
Type "A" screw
5 EA
Type "B" screw
2 EA
Type "C" screw
2 EA
Remote control
holder
1 EA
1 EA (5.0 kW)
2 EA (6.6 kW)
The feature can be changed according to type of model.
Type “B” screw
5.0 kW : ڸØ9.52 (3/8) ơ Ø12.7 (1/2)
6.6 kW : ڸØ9.52 (3/8) ơ Ø12.7 (1/2)
ڹØ15.88 (5/8) ơ Ø12.7 (1/2)
Installation Tool
