INSTALLATION INSTRUCTIONS
65
ENGLISH
NOTE
1. The above table shows the correlation between the air rates and E.S.P.
2. Be sure to set the value referring table 1. Unexpected set value will cause mal-function.
3. Table 1 is based at 230 V. According to the fluctuation of voltage, air flow rate varies.
Chassis
Capacity
(kBtu/h)
Grade Step CMM
Static Pressure [mmAq(Pa)]
0(0) 1(10) 2(20) 3(29) 4(39) 5(49)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06
L5 9
Standard
Compact
LOW
8 76 87 96 106 116 116
MID
9.5 87 96 106 114 120 120
HIGH
11.5 101 109 118 125 130 130
L5 12
Standard
Compact
LOW
8 76 87 96 106 116 116
MID
9.5 87 96 106 114 120 120
HIGH
11.5 101 109 118 125 130 130
L6 18
Standard
Compact
LOW
10 82 87 90 96 106 116
MID
12.5 92 98 105 109 119 128
HIGH
15 100 106 112 122 129 137
L3 24
Standard
Compact
LOW
12 89 95 102 106 120 130
MID
16 102 108 115 125 131 139
HIGH
20 125 131 136 141 142 147
L5 12 High
LOW
8 76 87 96 106 116 116
MID
9.5 87 96 106 114 120 120
HIGH
11.5 101 109 118 125 130 130
L3 18 High
LOW
10 80 90 95 100 110 120
MID
14 97 103 109 117 126 134
HIGH
18 115 122 127 133 138 142
Installer Setting - Static Pressure Step Setting
This function is applied to only duct type. Setting this in other cases will cause malfunction.
This function is only available on some products.
This is the function that static pressure of the product is divided in 11 steps for setting.
Ceiling Concealed Duct – Low static
Table 1
