LG CM24F User Manual

INSTALLATION INSTRUCTIONS
67
ENGLISH
Chassis
Capacity
(kBtu/h)
Grade Step CMM
Static Pressure [mmAq(Pa)]
5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 14(137) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
M2 42
Standard
Compact
LOW 28 100 103 106 110 114 118 121 125 128 133 136
MID 33 108 111 114 118 122 125 128 131 134 138 140
HIGH 38 117 120 124 127 130 133 135 138 140 144 147
Chassis
Capacity
(kBtu/h)
Grade Step CMM
Static Pressure [mmAq(Pa)]
4(39) 5(49) 6(59) 7(69) 8(78) 9(88) 10(98) 11(108) 12(118) 13(127) 15(147)
Setting Value
32:01 32:02 32:03 32:04 32:05 32:06 32:07 32:08 32:09 32:10 32:11
M2 36
Standard
Compact
LOW 24 88 91 95 100 101 108 113 115 118 118 118
MID 28 93 97 101 105 108 115 118 120 124 124 124
HIGH 32 101 105 109 112 115 119 123 126 128 128 128
M3 48
Standard
Compact
LOW 28 74 76 79 82 89 92 94 96 99 102 107
MID 34 78 82 84 89 94 96 98 101 104 106 112
HIGH 40 83 89 92 94 98 100 102 105 108 110 116
M3 48 High
LOW 28 74 76 79 82 89 92 94 96 99 102 107
MID 34 78 82 84 89 94 96 98 101 104 106 112
HIGH 40 83 89 92 94 98 100 102 105 108 110 116
M3 36 High
LOW 28 74 76 79 82 89 92 94 96 99 102 107
MID 34 78 82 84 89 94 96 98 101 104 106 112
HIGH 40 83 89 92 94 98 100 102 105 108 110 116
M3 42 High
LOW 28 74 76 79 82 89 92 94 96 99 102 107
MID 34 78 82 84 89 94 96 98 101 104 106 112
HIGH 40 83 89 92 94 98 100 102 105 108 110 116
M3 60
Standard
Compact
LOW 40 82 89 92 94 98 100 102 105 108 110 113
MID 45 90 92 96 98 102 104 106 109 112 114 117
HIGH 50 94 97 100 104 107 109 112 115 117 119 121
