11. EXPLODED VIEW & REPLACEMENT PART LIST
- 198 -
Level Ref No Part Name Part Number Spec Color Remark
7 D801 DIODE,TVS EDTY0008602 SOD-323 ,13.3 V,400 W,R/TP ,PB-FREE
7FB500 FILTER,BEAD,CHIP SFBH0000903 600 ohm,1005 ,
7 FL100 FILTER,SEPERATOR SFAY0009201 , , dB, dB, dB, dB,ETC ,
7 FL101 FILTER,SAW,DUAL SFSB0000601
836.5 MHz,25 MHz,4.4 dB,17 dB,897.5 MHz,35 MHz,4.4
dB,10 dB,3.2*2.5*1.5 ,SMD ,Pb-free_Tx Dual SAW &
Switch Module
7 FL102 DUPLEXER,PCS SDPY0002902
1880 MHz,1960 MHz,3.8 dB,3.5 dB,43 dB,52
dB,3.8*3.8*1.4 ,SMD ,FBAR
7 FL103 FILTER,SAW,DUAL SFSB0001601
836.5 MHz,25 MHz,2.2 dB,40 dB,1880 MHz,58.75 MHz,4
dB,30 dB,2.0*1.6*0.68 ,SMD
,824M~849M,1850.625M~1909.375M,10p,B,50,50,DCN+
USPCS Tx,BIDIR ,; ,836.5, 1880 ,2.0*1.6*0.68 ,SMD
,R/TP
7 FL500 FILTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF)
7 FL501 FILTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF)
7 FL502 FILTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF)
7 FL503 FILTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF)
7 FL504 FILTER,EMI/POWER SFEY0011701 SMD ,SMD ,18 V,4ch. EMI_ESD Filter (10 Ohm,7.5pF)
7 FL505 FILTER,EMI/POWER SFEY0011401 SMD ,SMD, 18V, 4ch, EMI_ESD Filter (100 Ohm, 7.5pF)
7 FL506 FILTER,EMI/POWER SFEY0011401 SMD ,SMD, 18V, 4ch, EMI_ESD Filter (100 Ohm, 7.5pF)
7 FL507 FILTER,EMI/POWER SFEY0011401 SMD ,SMD, 18V, 4ch, EMI_ESD Filter (100 Ohm, 7.5pF)
7 FL508 FILTER,EMI/POWER SFEY0011401 SMD ,SMD, 18V, 4ch, EMI_ESD Filter (100 Ohm, 7.5pF)
7 FL900 FILTER,SAW SFSY0034301
719 MHz,2.0*1.6*0.68 ,SMD ,716.5M~721.5M, IL 3.0,
4pin, U-U, 50-50, MediaFLO ,; ,719 ,2.0*1.6*0.68 ,SMD
,R/TP
7 L109 INDUCTOR,CHIP ELCH0001401 15 nH,J ,1005 ,R/TP ,Pb Free
7 L124 INDUCTOR,CHIP ELCH0005001 2.2 nH,S ,1005 ,R/TP ,
7 L125 INDUCTOR,CHIP ELCH0001048 10 nH,J ,1005 ,R/TP ,PBFREE
7 L127 INDUCTOR,CHIP ELCH0004706 10 nH,J ,1005 ,R/TP ,
7 L130 INDUCTOR,CHIP ELCH0001408 6.8 nH,J ,1005 ,R/TP ,Pb Free
7 L132 INDUCTOR,CHIP ELCH0004709 3.3 nH,S ,1005 ,R/TP ,
7 L134 INDUCTOR,CHIP ELCH0001040 3.9 nH,S ,1005 ,R/TP ,PBFREE
7 L600 INDUCTOR,CHIP ELCH0005019 68 nH,J ,1005 ,R/TP ,
7 L601 INDUCTOR,CHIP ELCH0005019 68 nH,J ,1005 ,R/TP ,
7 L800 INDUCTOR,CHIP ELCH0001430 100 nH,J ,1005 ,R/TP ,PBFREE
7 L801 INDUCTOR,CHIP ELCH0001430 100 nH,J ,1005 ,R/TP ,PBFREE
7 L900 INDUCTOR,CHIP ELCH0005004 22 nH,J ,1005 ,R/TP ,
7 L901 INDUCTOR,CHIP ELCH0005005 27 nH,J ,1005 ,R/TP ,
7 L908 INDUCTOR,CHIP ELCH0005011 1.5 nH,S ,1005 ,R/TP ,
7 L909 INDUCTOR,CHIP ELCH0005014 5.6 nH,S ,1005 ,R/TP ,
7 L910 RES,CHIP,MAKER ERHZ0000401
0 ohm,1/16W ,J ,1005 ,R/TP
