11. EXPLODED VIEW & REPLACEMENT PART LIST
- 199 -
Level Ref No Part Name Part Number Spec Color Remark
7R100 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP
7R108 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
7R109 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
7R111 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
7R112 RES,CHIP,MAKER ERHZ0000404 1 Kohm,1/16W ,J ,1005 ,R/TP
7R113 RES,CHIP,MAKER ERHZ0000443 2200 ohm,1/16W ,J ,1005 ,R/TP
7R115 RES,CHIP,MAKER ERHZ0000512 82 ohm,1/16W ,J ,1005 ,R/TP
7R116 RES,CHIP,MAKER ERHZ0000512 82 ohm,1/16W ,J ,1005 ,R/TP
7R117 RES,CHIP,MAKER ERHZ0000512 82 ohm,1/16W ,J ,1005 ,R/TP
7R119 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
7R120 RES,CHIP,MAKER ERHZ0000408 110 ohm,1/16W ,J ,1005 ,R/TP
7R121 RES,CHIP,MAKER ERHZ0000408 110 ohm,1/16W ,J ,1005 ,R/TP
7R122 RES,CHIP,MAKER ERHZ0000527 200 ohm,1/6W ,J ,1005 ,R/TP
7R124 RES,CHIP,MAKER ERHZ0000490 51 ohm,1/16W ,J ,1005 ,R/TP
7 R600 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R601 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R602 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R603 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R604 RES,CHIP ERHY0000280 100K ohm,1/16W,J,1005,R/TP
7 R605 RES,CHIP ERHY0000280 100K ohm,1/16W,J,1005,R/TP
7 R606 RES,CHIP ERHY0000290 300K ohm,1/16W,J,1005,R/TP
7 R607 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R608 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R609 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R610 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R611 RES,CHIP,MAKER ERHZ0000406 100 Kohm,1/16W ,J ,1005 ,R/TP
7 R612 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
7 R700 RES,CHIP,MAKER ERHZ0003901
0.1 ohm,1/4W ,F ,2012 ,R/TP ,; ,0.1 ,1% ,1/4W ,2012
,R/TP
7 R803 RES,CHIP,MAKER ERHZ0000288 470 Kohm,1/16W ,F ,1005 ,R/TP
7 R804 RES,CHIP,MAKER ERHZ0000537 680000 ohm,1/16W ,F ,1005 ,R/TP
7 R805 RES,CHIP,MAKER ERHZ0000204 100 Kohm,1/16W ,F ,1005 ,R/TP
7 R806 RES,CHIP,MAKER ERHZ0000537 680000 ohm,1/16W ,F ,1005 ,R/TP
7 R900 RES,CHIP,MAKER ERHZ0000212 12 Kohm,1/16W ,F ,1005 ,R/TP
7 R901 RES,CHIP,MAKER ERHZ0000499 5600 ohm,1/16W ,J ,1005 ,R/TP
7 R902 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
7 R903 RES,CHIP,MAKER ERHZ0000405
10 Kohm,1/16W ,J ,1005 ,R/TP
