11. EXPLODED VIEW & REPLACEMENT PART LIST

- 200 -

Level Ref No Part Name Part Number Spec Color Remark

7 R904 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP

7 R905 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP

7 R907 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP

7 R908 RES,CHIP,MAKER ERHZ0000401 0 ohm,1/16W ,J ,1005 ,R/TP

7 S600 CONN,SOCKET ENSY0015801 8 PIN,ETC , ,1.1 mm,H=1.9, Detect Pin

7 SW100 CONN,RF SWITCH ENWY0002304 STRAIGHT ,SMD ,0.8 dB,MUSE MODEL

7 SW101 CONN,RF SWITCH ENWY0003901 ,SMD , dB,

7 U101 PAM SMPY0014801

34.5 dBm,55 %, A, dBc, dB,6x8x1.2 ,SMD ,Edge PAM for

QCT ,; , , , , , , , ,SMD ,R/TP ,16

7 U102

COUPLER,RF

DIRECTIONAL

SCDY0003401

-22 dB,-0.2 dB,-37 dB,1.0*0.58*0.35 ,SMD ,824M ~

849M, 4pin, Pb Free

7 U103 DUPLEXER,DCN SDDY0004101

836.5 MHz,881.5 MHz,2.0 dB,2.7 dB,49 dB,61

dB,3.0*2.5*1.25 ,SMD ,

7 U104

COUPLER,RF

DIRECTIONAL

SCDY0003402

-20 dB,-0.25 dB,-35 dB,1.0*0.58*0.35 ,SMD ,1850M ~

1910M, 4pin, Pb Free

7 U105 PAM SMPY0015801

28 dBm,39 %, A, dBc, dB,3x5x1 ,SMD ,HELP3 Dual PAM

,; , , , , , , , ,R/TP ,R/TP ,14

7 U700 IC EUSY0332901

WDFN ,8 PIN,R/TP ,-12V, 6.3A, Single P-MOSFET &

DUAL Transistor

7U900 IC EUSY0275101 QFN(5*5) ,32 PIN,R/TP ,MediaFLO RF Receiver IC

7U901 IC EUSY0275201

BCCS(9*9) ,116 PIN,R/TP ,baseband IC within the FLO

chipset

7 VA500 VARISTOR SEVY0004101 5.6 V, ,SMD ,360pF, 1005

7 VA501 VARISTOR SEVY0003801 18 V, ,SMD ,

7 VA502 VARISTOR SEVY0003801 18 V, ,SMD ,

7 VA600 DIODE,TVS EDTY0009401
