11. EXPLODED VIEW & REPLACEMENT PART LIST
- 201 -
Level Ref No Part Name Part Number Spec Color Remark
7 VA612 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7 VA613 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7 VA614 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7 VA615 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7 VA616 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7 VA617 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7VA800 VARISTOR SEVY0003801 18 V, ,SMD ,
7VA801 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7VA802 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7VA803 VARISTOR SEVY0001001 14 V, ,SMD ,50pF, 1005
7VA804 DIODE,TVS EDTY0009401
VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW
,[empty] ,[empty] ,2P ,1
7VA805 DIODE,TVS EDTY0009401
VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW
,[empty] ,[empty] ,2P ,1
7VA806 VARISTOR SEVY0003801 18 V, ,SMD ,
7VA807 VARISTOR SEVY0004101 5.6 V, ,SMD ,360pF, 1005
7 ZD1 DIODE,TVS EDTY0009401
VMN2 ,5 V,10 W,R/TP ,1.0*0.6*0.4 ,; , ,7.82V , , ,100mW
,[empty] ,[empty] ,2P ,1
6 SAFD00 PCB ASSY,MAIN,SMT TOP SAFD0094101
7 C103 CAP,CERAMIC,CHIP ECCH0001002 180 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C104 CAP,CERAMIC,CHIP ECCH0001002 180 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C105 CAP,CERAMIC,CHIP ECCH0000107 6 pF,50V,D,NP0,TC,1005,R/TP
7 C106 CAP,CERAMIC,CHIP ECCH0000107 6 pF,50V,D,NP0,TC,1005,R/TP
7 C107 CAP,CERAMIC,CHIP ECCH0000105 4 pF,50V,C,NP0,TC,1005,R/TP
7 C108 CAP,CERAMIC,CHIP ECCH0001002 180 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C109 CAP,CHIP,MAKER ECZH0000816 12 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C110 CAP,CERAMIC,CHIP ECCH0001002 180 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C111 CAP,CERAMIC,CHIP ECCH0000149 3.3 nF,50V,K,X7R,HD,1005,R/TP
7C114 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7C117 CAP,CHIP,MAKER ECZH0000816 12 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C120 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP
7C122 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7C123 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7C124 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7C125 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7C126 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C130 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C133 CAP,CERAMIC,CHIP ECCH0000198
2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP
