11. EXPLODED VIEW & REPLACEMENT PART LIST
- 202 -
Level Ref No Part Name Part Number Spec Color Remark
7 C134 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C135 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C136 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C137 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C138 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C139 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C141 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7 C142 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C148 CAP,CERAMIC,CHIP ECCH0000120 39 pF,50V,J,NP0,TC,1005,R/TP
7C156 CAP,CHIP,MAKER ECZH0004402
100000 pF,16V ,Z ,X7R ,TC ,1005 ,R/TP , , ,[empty]
,[empty] ,[empty] ,[empty] ,[empty] ,[empty]
7C157 CAP,CHIP,MAKER ECZH0000830 33 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C158 CAP,CERAMIC,CHIP ECCH0000155 10 nF,16V,K,X7R,HD,1005,R/TP
7C160 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C161 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7C164 CAP,CERAMIC,CHIP ECCH0000143 1 nF,50V,K,X7R,HD,1005,R/TP
7C169 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C170 CAP,CERAMIC,CHIP ECCH0000105 4 pF,50V,C,NP0,TC,1005,R/TP
7C172 CAP,CERAMIC,CHIP ECCH0000105 4 pF,50V,C,NP0,TC,1005,R/TP
7C173 CAP,CERAMIC,CHIP ECCH0000127 82 pF,50V,J,NP0,TC,1005,R/TP
7C174 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7C176 INDUCTOR,CHIP ELCH0003828 2.4 nH,J ,1005 ,R/TP ,MLCI
7C177 CAP,CHIP,MAKER ECZH0000822 1.5 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
7C178 CAP,FILM,MPP ECFD0000105
2.2 nF,16V ,J ,STD ,SMD ,1608 mm,R/TP ,; , ,5%
,[empty] ,[empty] ,-55TO+125C ,[empty] ,1.6X0.8X0.7MM
,R/TP
7C179 CAP,CHIP,MAKER ECZH0000822 1.5 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
7C180 CAP,CERAMIC,CHIP ECCH0000901 2.2 pF,50V ,C ,NP0 ,TC ,1005 ,R/TP
7C181 CAP,CERAMIC,CHIP ECCH0000187 150 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C183 CAP,CERAMIC,CHIP ECCH0000198 2.2 uF,6.3V ,M ,X5R ,TC ,1005 ,R/TP
7C184 CAP,CHIP,MAKER ECZH0003124 68 nF,16V ,K ,X7R ,HD ,1005 ,R/TP
7C185 CAP,CERAMIC,CHIP ECCH0000118 30 pF,50V,J,NP0,TC,1005,R/TP
7C186 CAP,CERAMIC,CHIP ECCH0000118 30 pF,50V,J,NP0,TC,1005,R/TP
7C187 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7C188 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7C189 CAP,CERAMIC,CHIP ECCH0000129 120 pF,50V,J,NP0,TC,1005,R/TP
7C190 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7C191 CAP,CERAMIC,CHIP ECCH0000115
22 pF,50V,J,NP0,TC,1005,R/TP
