11. EXPLODED VIEW & REPLACEMENT PART LIST
- 206 -
Level Ref No Part Name Part Number Spec Color Remark
7 C804 CAP,TANTAL,CHIP ECTH0002002
33 uF,10V ,M ,L_ESR ,2012 ,R/TP ,; , ,[empty] ,[empty] ,
,-55TO+125C , ,2.2X1.1X1.1MM ,[empty] ,[empty]
,[empty]
7 C807 CAP,CERAMIC,CHIP ECCH0000122 47 pF,50V,J,NP0,TC,1005,R/TP
7 C808 CAP,CERAMIC,CHIP ECCH0000122 47 pF,50V,J,NP0,TC,1005,R/TP
7C813 CAP,CHIP,MAKER ECZH0001215 1 uF,10V ,K ,X5R ,TC ,1005 ,R/TP
7 C929 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C930 CAP,CHIP,MAKER ECZH0000813 100 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 CN803 CONNECTOR,ETC ENZY0018801 PIN, mm,ETC , ,RCS=1.35
7 D700 DIODE,SWITCHING EDSY0011901
EMD2 ,30 V,1 A,R/TP ,VF=1.5V(IF=200mA) ,
IR=30uA(VR=10V)
7D802 DIODE,TVS EDTY0009201
1.6*1.6*0.6 ,5 V,150 W,R/TP , ,; ,5 ,6 ,15 ,40 ,- ,[empty]
,R/TP ,6P ,4
7 FB800 FILTER,BEAD,CHIP SFBH0009801 600 ohm,1005 ,DC Res.0.6ohm, R.C.500mA
7 FL104 FILTER,SAW SFSY0030001 881.5 MHz,1.35*1.05*0.6 ,SMD ,DCN_Rx_SAW
7 FL105 FILTER,SAW SFSY0034601
1960 MHz,1.4*1.1*0.6 ,SMD ,1930M~1990M, IL 3.3,
5pin, U-B, 50-100, USPCS Rx ,; ,1960 ,1.4*1.1*0.6 ,SMD
,R/TP
7 L100 INDUCTOR,CHIP ELCH0004733 4.3 nH,S ,1005 ,R/TP ,Coil
7 L101 NOT ASSEMBLE 99999999999 NOT ASSEMBLE Color Unfixed
7 L102 NOT ASSEMBLE 99999999999 NOT ASSEMBLE Color Unfixed
7 L104 INDUCTOR,CHIP ELCH0004733 4.3 nH,S ,1005 ,R/TP ,Coil
7 L106 INDUCTOR,CHIP ELCH0001034 3.3 nH,S ,1005 ,R/TP ,PBFREE
7 L107 INDUCTOR,CHIP ELCH0005002 2.7 nH,S ,1005 ,R/TP ,
7 L108 INDUCTOR,CHIP ELCH0001052 18 nH,J ,1005 ,R/TP ,PBFREE
7 L110 INDUCTOR,CHIP ELCH0001034 3.3 nH,S ,1005 ,R/TP ,PBFREE
7 L111 INDUCTOR,CHIP ELCH0004715 27 nH,J ,1005 ,R/TP ,
7 L113 NOT ASSEMBLE 99999999999 NOT ASSEMBLE Color Unfixed
7 L114 INDUCTOR,CHIP ELCH0005019 68 nH,J ,1005 ,R/TP ,
7 L116 INDUCTOR,CHIP ELCH0004715 27 nH,J ,1005 ,R/TP ,
7 L117 INDUCTOR,CHIP ELCH0001421 47 nH,J ,1005 ,R/TP ,PBFREE
7 L118 INDUCTOR,CHIP ELCH0004711 22 nH,J ,1005 ,R/TP ,
7 L119 INDUCTOR,CHIP ELCH0001052 18 nH,J ,1005 ,R/TP ,PBFREE
7 L120 INDUCTOR,CHIP ELCH0003827 47 nH,J ,1005 ,R/TP ,chip coil
7 L121 INDUCTOR,CHIP ELCH0004711 22 nH,J ,1005 ,R/TP ,
7 L123 INDUCTOR,CHIP ELCH0001421 47 nH,J ,1005 ,R/TP ,PBFREE
7 L128 INDUCTOR,CHIP ELCH0005113 15 nH,J ,1005 ,R/TP ,
7 L136 INDUCTOR,CHIP ELCH0001009 1.2 nH,S ,1005 ,R/TP ,
7 L138 INDUCTOR,CHIP ELCH0001022 56 nH,J ,1005 ,R/TP ,Pb Free
7 L139 INDUCTOR,CHIP ELCH0004711
22 nH,J ,1005 ,R/TP ,
